STEEL & STAINLESS STEEL FINISHING
Black Oxide for Industrial Parts
Black oxide for steel and stainless steel industrial parts and series production.
Give your parts a black finish with minimal dimensional change.
For recurring orders and production runs, share your drawings, quantities and requirements to request a quote.
Parts ready in 48 hours
Parts ready in 48 hours
Timing is confirmed with your quote, based on your quantities and requirements.
1 million parts treated annually
Industrial parts finished every year in our Longueuil facility.
What Is Black Oxide?
Black oxide is a chemical conversion treatment that forms a thin black oxide layer on the surface of steel or stainless steel. Unlike paint, it changes the metal’s surface rather than covering it with a thick coating.
The treatment produces a black appearance with minimal dimensional change. An oil finish is then applied to help protect the parts against corrosion.
A Black Finish That Preserves the Details
Black oxide is an option for parts that need a dark appearance without the buildup of a thick coating.
Minimal Dimensional Change
Preserve the fit of closely matched components with a treatment that adds negligible dimensional buildup.
Reduced Light Reflection
Darken the metal surface and reduce glare. The final appearance depends on the original surface finish and the oil applied after treatment.
Protection With an Oil Finish
The oil post-treatment helps improve corrosion resistance during handling, storage and use.
Have specific requirements for appearance, fit or operating conditions? Share them with our team when requesting your quote.
Discuss Your RequirementsSee the Finish. Picture Your Parts.
Finishing for Industrial Manufacturers
- Aerospace
- Automotive
- Manufacturing
Black Oxide Capabilities
Check our materials, tank dimensions and treatment specifications, or send us your drawing to discuss your project.
- Materials
- Steel and stainless steel
- Tank capacities
Steel + stainless steel
18″ × 34″ × 15″ deep
Steel
36″ × 48″ × 15″ deep
16″ × 72″ × 15″ deep
- Specifications
- QQ-P-35C · TYPE VI
- MIL-DTL-13924D · CLASS 1
- MIL-DTL-13924D · CLASS 4
- Finish
- Black oxide + oil post-treatment
Usable capacity depends on your part’s shape, orientation and handling requirements. Include your material grade, dimensions and required specification so we can confirm suitability.
Send Your Project DetailsOur Black Oxide Process
From cleaning to the final oil treatment, each stage prepares the finish result your parts need.
The parts are cleaned to remove oils, grease and surface contaminants before the black oxide treatment.
The parts are immersed in a heated chemical bath that converts the metal surface into a thin black oxide layer.
After treatment and rinsing, an oil finish is applied to help improve corrosion resistance.
A Finishing Partner for Your Project
20+ years
Experience You Can Rely On
With more than 20 years of metal finishing experience, Placage Boucherville helps customers find the right treatment for their parts.
Specifications
Your Technical Requirements Matter
Send us your drawing, material grade and required treatment specification. We’ll review your project requirements, including any compliance documentation you need.
Timing
Based on Your Production Schedule
Working toward a production deadline? Share your required date so we can discuss processing availability and coordinate your order.
Hear from customers who trust Placage Boucherville with their finishing projects.
From Project Details to Finished Parts
- 01
Send Your Requirements
Drawings or photos, quantities, material grade and required date.
- 02
Confirm Your Quote
We confirm the treatment, pricing and turnaround with you.
- 03
Arrange Your Order
Coordinate the receipt of your parts with our team.
Request Your Black Oxide Quote
Tell us about your parts and your finishing requirements. Share the details you have, and our team will follow up to review your project.
Prefer to speak with us?
- Phone
- 450 641-8229
